M6 Washer (82)
M8 Nylon Locknut (58)
M6 Locknut (87)
M8 Washer (59)
M10 Nylon Locknut (56)
M4 Washer (33)
M10 x 70mm Bolt (86)
M10 x 51mm Bolt (66)
M10 x 46mm Bolt (81)
M10 x 63mm Bolt (75)
M10 x 67mm Bolt (71)
M10 x 85mm Bolt (67)
M10 x 45mm Button Bolt (77)
M10 x 155mm Bolt (74)
M8 x 65mm Bolt (68)
M8 x 22mm Shoulder Bolt (65)
M6 x 63mm Screw (70)
M6 x 16mm Screw (62)
M4 x 20mm Self-tapping Screw (69)
M10 x 77mm Bolt (79)
M5 Washer (72)
M8 x 63mm Carriage Bolt (78)
M10 Washer (57)
M5 x 20mm Self-tapping Screw (64)
M10 Large Washer (80)
M12 Nut (84)
Large Washer (85)
PART IDENTIFICATION CHART
See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST near the end of this manual. Note: Some small parts may
have been preattached. If a part is not in the parts bag, check to see if it has been preattached.
5
