The Four Stages of the Assembly Process
Frame Assembly—You will begin by assembling
the base and the uprights that form the skeleton of
the weight system.
Arm Assembly—During this stage you will assem-
ble the arms and other moving parts.
Cable Assembly—During this stage you will attach
the cables and pulleys that connect the arms to the
weights.
Seat Assembly—During the final stage you will
assemble the seat, the backrest, and other parts.
Before beginning assembly, carefully read the fol-
lowing information and instructions:
• Assembly requires two persons.
• Because of its size, the weight system should be
assembled in the location where it will be used.
Make sure that there is enough clearance to walk
around the weight system while you assemble it.
• To make assembly as easy as possible, we have
divided the assembly process into four stages.
The parts needed for each stage are found in
individual bags.
Important: Wait until you begin
each stage to open the parts bag for that
stage. Place all parts in a cleared area and
remove the packing materials. Do not dispose of
the packing materials until assembly is complet-
ed.
• Tighten all parts as you assemble them, unless
instructed to do otherwise.
• As you assemble the weight system, make sure
all parts are oriented as shown in the drawings.
• For help identifying small parts, use the PART
IDENTIFICATION CHART on page 5.
• Assembly requires the included hex key(s)
and the following tools (not included):
two adjustable wrenches
one rubber mallet
one standard screwdriver
one Phillips screwdriver
Assembly may be more convenient if you have a
socket set, a set of open-end or closed-end
wrenches, or a set of ratchet wrenches.
ASSEMBLY
Make Assembly Easier
Everything in this manual is designed to ensure
t
hat the weight system can be assembled suc-
cessfully by almost anyone. By setting aside
plenty of time, assembly will go smoothly.
