Weider Easy Compact 90 User Manual

7
3. Attach the Curl Pad (23) to the Curl Post (6)
with two M6 x 16mm Screws (67).
3
2
3
67
Make sure that all parts are properly tightened. The use of the remaining parts will be explained in ADJUSTMENT,
beginning on page 8.
Before using the weight system, pull each cable a few times to make sure that the cables move smoothly
around the pulleys. If one of the cables does not move smoothly, find and correct the problem.
IMPORTANT: If
the cables are not properly installed, they may be damaged when heavy weight is used. See the CABLE
DIAGRAM on page 14 for proper cable routing. If there is any slack in the cables, you will need to
remove the slack by tightening the cables. See MAINTENANCE on page 13.
6

Weider Easy Compact 90 Specifications

General

Brand	Weider
Model	Easy Compact 90
Category	Home Gym
Language	English
