Weider Precision 200 - Connecting the Leg Lever; Using the Curl Pad

10
44
5
42
23
5
35
USING THE CURL PAD
To use the Curl Pad (23), first remove the upper
Seat Frame Cap (35) from the Seat Frame (4).
Insert the Curl Post (13) into the Seat Frame, and
secure it with the Curl Post Knob (47).
Next, attach the Lat Bar (42) to the Leg Lever (5)
with a Chain (44) and two Cable Clips (43).
When performing an exercise that does not require
the Curl Pad (23), remove the Curl Pad and insert
the Seat Frame Cap (35) into the Seat Frame (4).
CONNECTING THE LEG LEVER
T
o use the Leg Lever (5), first slide the Seat Frame
(4) on a set of pegs on the Frame (1).
Next, attach a Chain (44) between the Leg Lever (5)
and the Low Cable (31) with two Cable Clips (43).
4
44
43
43
43
43
1
31
47
6
4
