9
ATTACHING ACCESSORIES TO THE LOW
PULLEY STATION
To use accessories with the low pulley station, first
r
emove the seat (see ATTACHING THE SEAT
below).
Attach the Lat Bar (42) to the Low Cable (31) at the
low pulley station with a Cable Clip (43). For some
exercises, attach a Chain (44) between the Lat Bar
and the Cable with two Cable Clips.
Adjust the
length of the Chain between the Lat Bar and the
Cable so that the Lat Bar is in the correct starting
position for the exercise to be performed.
Attach the Handle Strap (91) to the Low Cable (31) in
the same way.
1
ATTACHING THE SEAT
To use the Seat (22), slide the Seat Frame (4) onto
a set of pegs on the Frame (1).
When the Seat (22) is not in use, set the Seat
Frame (4) away from the weight system.
22
USING THE PRESS ARMS
To use the Press Arms (7, 8) pull them away from
the Press Arm Magnets (39) and lower them.
When the Press Arms (7, 8) are not in use, raise
them until the Press Arm Magnets (39) hold them
securely
.
39
43
42
44
91
31
43
4
8
7
39
