6
2. Locate the two Mounting Pegs (not shown) on
the back of the Backrest (21). Insert the
M
ounting Pegs into the indicated brackets on
the Frame (1), and then slide the Backrest
d
ownward.
Next, slide the Seat Frame (4) downward onto a
set of pegs on the Frame (1).
Apply some of the included grease to the barrel
of an M10 x 65mm Bolt Set (68). Attach the Leg
Lever (5) to the Seat Frame (4) with the Bolt
Set.
Make sure that the barrel of the Bolt Set
is inserted through both sides of the bracket
on the Seat Frame.
2
1
21
Bracket
68
4
68
5
Grease
Bracket
To Next Page
