c. The IP address first three sections, subnet mask, and default gateway need
to be the same as those for the computer. The last section of the IP address
needs to be different from that of the computer IP address.
4. Click Connect and check TCP port.
5. In the NcStudio function bar, click Set > System Parameters. In the
External Device > 3.0 Monitoring category, set Enable Camera to Yes.
6. In the camera monitor area, click login in the right-click menu. Enter information in
the blank fields.
7. Select the camera type, camera IP address, port number, username, and password.
After logging in, the camera image will be displayed in the camera monitoring area.
Double-click in the camera monitor area to switch between different numbers of cameras.
If the camera is replaced in the future, click Logout in the right-click menu in the camera
monitor area and repeat the previous steps to log in again.
