WEIHONG LS6000M - Page 65

上海维宏电子科技股份有限公司
SHANGHAI WEIHONG ELECTRONIC TECHNOLOGY CO., LTD.
62 / 116
 Output working voltage: 24V.
 Port COM: 0V output.
 Rated current: 200 mA.
 Darlington transistor.
EX31A extension terminal board
The port definitions are shown below:
