Emptying the condensate collecting tray into a sink drain or similar drain
1.
Pull the condensate collecting tray pan back a little. Slightly tilt the
condensate drain pan as shown in the figure to the left so that you can
pull it backwards beyond the stop.
2.
Lift the condensate collecting tray out from the loading trolley, making
sure to keep it level.
3.
Empty the condensate collecting tray into a drain.
Putting the condensate collecting tray in place
1.
Put the condensate collecting tray in place at the bottom of the loading
trolley
.
2.
Slide the condensate collecting tray forward and tilt it a little until it
slides behind the retainer flange.
Check to make sure that the condensate collecting tray is being prop-
erly held in place by the retainer flange.
5 How to Clean the Combi Oven
Operating Manual 92
