12 Chapter 1 Introduction Welch Allyn CP 100 Electrocardiograph
About the Patient Cable and Leads
The patient cable processes the patient’s ECG data and transmits it to the
electrocardiograph. To make handling convenient, the ten leads are arranged to point
toward the appropriate parts of the body. The cable rake, which slides easily, prevents the
chest leads from tangling.
Figure 11. Patient Cable and Leads
Left leg lead
Left arm lead
Right leg lead
Right arm lead
Chest leads
Electrocardiograph
connector
Cable
rake
