Directions for Use Chapter 4 Reviewing the ECG Settings 33
About Auto ECG Reports
An Auto ECG is a report of ECG data in a user-defined format. For an example, see
Figure 21. To learn how to set up or interpret a report, see the references on page 34.
Figure 21. Auto Report Example — 3x4 +3R Lead Arrangement
E. 3 rows, 4 columns
F. Rhythm leads
A. Patient data B. ECG measurements C. Interpretation (optional)
L. Frequency rangeN. Paper speed
K. AC filter
J. Date and time
H. Device ID
G. Software version
D. Report status label
O. Calibration
pulse
M Gain
I. Practice ID
