3. Remove the battery cover by lifting the bottom of the cover away from
the probe tip. See Figure 36.
Figure 36
4. Push down on the positive (+) end of the battery. Battery will eject.
See Figure 37.
Figure 37
C-44
USE ONLY SPECIFIED CHARGER
RECHARGEABLE BATTERY 2.4 VOLTS 600mAh
CATALOG NO. 72900
Battery will
eject
Apply
Pressure
USE ONLY SPEC
RECHARGEABLE BA
CATALOG NO.
