5. Insert the replacement battery by placing the positive (+) end of the
battery against the spring in the holder. Push the battery lightly to
compress the spring, and lower the battery into the compartment.
See Figure 38.
NOTE: Insert the battery only as shown. Failure to observe the
correct polarity will prevent the instrument from functioning.
Figure 38
6. Replace the cover by inserting the tip end under the front cover, lowering
the opposite end, and replacing the screw.
7. Tighten screw in clockwise direction. To avoid stripping the screw
threads, do not tighten excessively.
C-45
USE ONLY SPECIFIED CHARGER
RECHARGEABLE BATTERY 2.4 VOLTS 600mAh
CATALOG NO. 72900
Appendix C
