CM2P201 User Guide
8
3 Module Overview
3.1 CMP201 Baseboard
CMP201
Basic Function
Baseboard
120 inputs & 120 outputs IP channel
3.2 Receiver Modules
Module
Description
CR2-DVBC-00
 4-channel DVBC receiving and descrambling
module with 1 RF female connector and 2 CI slots
CR2-DVBS2CI-00
 4-channel DVB-S/S2 receiving and descrambling
module with 2 RF connectors and 2 CI slots
CR2-DVBS2FTA-00/00A
 4/8-channel DVB-S/S2 receiving module with 4/8
RF connectors
CR2-DVBS2FTA-01
 4-channel DVB-S/S2/S2X FTA receiving module
with 4 RF connectors
CR2-8VSB-00
 4-channel 8VSB receiving module with 4 RF
connectors
CR2-DVBT2CI-00
 4-channel DVB-T/T2 receiving and descrambling
module with1 RF connectors and 2 CI slots
3.3 Encoder Modules
Module
Description
CE2-HDMI-00
CE2-HDMI-R01

4-channel HDMI HD encoder (broadcast level),
supports H.264 HD/SD, MPEG-2 SD, MPEG1L2,
AAC, AC3
 4-channel HDMI HD encoder(commercial grade),
supports H.264 HD/SD, MPEG1L2, AAC (optional),
AC3 (optional), supports overlay OSD subtitles,
station logo, two-dimensional code, does not
