CM2P201 User Guide
Click Advance Parameters to set Encoding Parameters & Stream Output Parameters &
MPEG-2 Output Parameters & MPEG4/MPEG4_AVC Output Parameters &Other Parameters
for CH1.1/CH2.1 separately.
CE2-HDMI-02 module supports up to two channels of audio and video input. Each channel includes
1 HDMI port and 1 RCA port. It supports dual audio encoding per channel which means one audio
track from HDMI input can be encoded into two different formats for output.
CE2-HDMI-02 >Output
This feature is specifically for single program encoding and IP output directly. Outputting in this way
will not occupy baseboard multicast bandwidth.
If you want to use IP output channels in the encoder module and the baseboard IP module at
same time, you should a avoid the multicast IP address conflict. If there are two same IP addresses
enabled meantime, all the multicast videos will be affected.
Destination IP Address and Destination Port: Using for multicast IP addresses or unicast IP
addresses and ports.
Enable Destination MAC: Generally, you do not need to enable this option. This is reserved for
exceptional cases where the unicast stream cannot be received with unicast IP addresses. You
can enable destination MAC and streaming out by setting Destination MAC.
To use Multiplexing mode at service level
1. Click on pencil icon . There will always be a BaseBoard selection for the IP output and
other Output options depending on the module inserted.
2. Select the correct Output and Channel you want to output the service to.
3. Check Multiplex on the channel you want to output to. You can output multiple services to one
channel or output one service to multiple channels.
