CM2P201 User Guide
10
CE2-HDMI-06

4-channel HDMI encoder (broadcast level),
supports H.264/H.265 HD/SD encoding (up to
1080p60), B frame and de-interlacing. supports
MPEG1-L2, AAC (optional) and AC3 (optional)
audio encoding. Also supports QR code, logo,
subtitles insertion.
3.4 Modulator Modules
Module
Description
CM2-QAMA-R00
CM2-QAMA-R01 / R01A
 supports modulating 16 non-adjacent or channels
with 1 RF female port for modulating output and 1
RJ45 network port is reserved for future use.
 supports modulating 4/8 adjacent channels with 1
RF female port for modulating output.
CM2-ATSC-R01/R01A
 supports 4/8 adjacent frequencies modulating with
1 RF female connector for output.
CM2-QAMB-R00
CM2-QAMB-R01 / R01A
 supports up to 16non-adjacent frequencies
modulating with 1 RF female connector for output
 supports up to 4/8 adjacent frequencies
modulating with 1 RF female connector for output
CM2-OFDM-R01 / R01A
 supports up to 4/8 adjacent frequencies
modulating with 1 RF female connector for output
CM2-ISDBT-R01/ R01A
 supports up to 4/8 adjacent frequencies
modulating with 1 RF female connector for output
CM2-MOD-02
 32-channel QAM-A modulation output module with
2 gigabit IP input ports, single port supports
512-channel input; 1 CAS interface (RJ45),
supports scrambling function; 1 RF output
interface, supports up to 32 QAM-A non-adjacent
frequencies modulating with independent
constellation mode configuration.
