CM2P201 User Guide
34
You can check program details by clicking the program item.
CR2-DVS2FTA-01 > Setting
Channel 1.1, 1.2,1.3 and 1.4, 4 LNBs are powered independently.
Name
Range
Satellite Frequency (MHz)
950~14500
Symbol Rate(KBaud)
1000~45000
LNB Frequency(MHz)
0~13550
LNB Power
Off/13v/18v
LNB 22KHz
Off/22KHz
The absolute value of the difference between the Satellite Frequency and the LNB Frequency must
be in the range [950, 2150].
Click the Apply button on the right side to make the changes made take effect.
CR2-DVS2FTA-01 > Biss
