CM2P201 User Guide
Click Advance Parameters
to set
Encoding Parameters & Stream Output Parameters & MPEG-2
Output Parameters & MPEG4/MPEG4_AVC Output Parameters &Other Parameters for
CH1.1/CH2.1 separately.
CE2-HDMI-02C module supports up to two channels of audio and video input. Each channel
includes 1 HDMI port and 1 DB-15port (2 channel share same one DB-15 port).
If video comes from HDMI, there are three options for encoding dual audio:
1. One audio comes from HDMI input and the another comes from analog input; the encoding format
can be the same or different;
2. One audio that comes from HDMI input can be encoded into two different formats for output.
3. One audio that comes from analog input can be encoded into two different formats for output.
If video comes from the component, there is only one choice for encoding dual audio:
1. One audio that comes from analog input can be encoded into two different formats for output.
CE2-HDMI-02C > Output
This feature is specifically for single program encoding and IP output directly. Outputting in this way
will not occupy baseboard multicast bandwidth.
If you want to use IP output channels in the encoder module and baseboard TSoIP module at
same time, you should avoid a multicast IP address conflict. If there are two same IP addresses
enabled meantime, all the multicast video will be affected.
Destination IP Address and Destination Port: Using for multicast IP addresses or unicast IP
addresses and ports.
Enable Destination MAC: Generally, you do not need to enable this option. This is reserved for
exceptional cases where the unicast stream cannot be received with unicast IP addresses, you
can enable destination MAC and streaming out by setting Destination MAC.
