OPERATION
ADJUSTMENTS
ADJUSTING DRIVE BELT TENSION (Figure R)
WARNING: Disconnect machine from the power source! Never make adjustments with the machine
running! Failure to comply may cause serious injury!
1. Unplug the machine from the power source.
2. Loosen the hex cap screw on the back of the cabinet that secures the motor.
3. Push or rotate the motor to increase or decrease tension. The belt is properly tensioned when moderate finger-
pressure on the belt between the two pulleys causes a 1/2” deflection.
4. Tighten the hex cap screw that secures the motor.
ON/OFF SWITCH (Figure 14)
1. To turn the saw ON, move the switch to the up (ON) position. (Fig. S)
2. To turn the saw OFF, move the switch to the down (OFF) position.
3. To lock the switch in the OFF position:
A) Wait until the band saw has come to a complete stop.
B) Remove the safety key from the switch housing. Store the safety key in
a safe place.
4. To unlock the switch and turn the saw ON, insert the safety key into the
switch, and move the switch to the ON position.
LED WORK LIGHT (Figure 14)
The LED work light has an adjustable gooseneck for precision control when aiming the light. The work light
switch is independent and may be turned ON or OFF separately from the band saw switch. The LED switch is a
smaller switch located directly above the main ON/OFF switch. (Fig. S)
MAINTENANCE
WARNING: For your own safety, turn the switch OFF and remove the plug from the electrical outlet
before performing maintenance or lubricating the band saw.
1. Remove the sawdust from the inside of the housing and blow out the sawdust from the motor.
2. Clean off the pitch which accumulates on the table, blade guides, and bearings.
3. Remove pitch and dust from the upper and lower wheels using a stiff brush. Do not use solvents.
4. Apply a thin coat of automotive polish to the table top for a slick surface.
5. Replace the wheel tires when worn.
WARNING: Replace the power cord immediately if it is worn, cut, or damaged in any way.

Fig. S
