EXPLODED VIEW & PARTS LIST
22
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 40401 Battery (2Ah) 1
2 40417-020 Battery Latch 1
3 40410-013 Button Spring 1
4 40421-004 Electronic Components 1
5 40439-086 Double Torsion Spring 1
6 40417-025 Shaft 1
7 40421-007 Left Handle 1
8 40413-014 Safety 1
9 40410-015 Spring 1
10 40421-010 Trigger 1
11 40421-011 Trigger Spring 1
12 40415-019 Self Tapping Screw 22
13 40421-013 Right handle 1
14 4021-023 Heat Shrinkable Tube 1
15 4017-020 Copper Strip 16
16 40421-016 Self Tapping Screw 6
17 4021-004 Cable Clamp 2
18 40421-018 Spring Connecting Line 1
19 4021-025 Telescoping Clamp 1
19-1 4021-026 Brace 1
19-2 4021-027 Hexagon Nut 1
19-3 40441-097 Pan Head Screws 1
19-4 4021-029 Brace Ring 1
20 40421-024 Tube Assembly 1
20-1 40421-033 Bassoon 1
20-2 4021-042 Large Ring 1
20-3 4021-037 Telescoping Clamp 1
20-4 4021-036 Cylindrical Pin 1
20-5 4021-038
Quick Clamping Adjust-
ing Bolt
1
20-6 40421-029 Connecting Bracket 1
20-7 40421-030 Fixed Pin 2
No. Part No. Description Qty.
20-8 4021-039 Locking Nut 1
20-9 40421-034 Flat Gasket 1
20-10 40421-035 Locking Nut 1
20-11 40421-032
Countersunk Head
Screws
1
20-12 40421-036 Washer 1
20-13 40421-037 In Pipe 1
21 40421-038 Button 1
22 40421-039
Connecting Handle Of
Left Casing
1
23 40421-040
Connecting Handle Of
Right Casing
1
24 40421-041 Self Tapping Screw 2
25 40421-042 Driven Button 1
26 40421-043 Steering Button Spring 1
27 40421-044 Left Housing 1
28 40421-045 Electronic Components 1
29 40421-046 Female Terminal 2
30 4021-022
Heat Shrinkable Tube
(Female)
1
31 40421-048 Nozzle Assembly 1
32 40421-049 Transparent Oil Tube 1
33 40421-050 Oil Pump Assembly 1
33-1 40421-051 Oil Pump Assembly 1
33-2 40421-052 Oil Pump Tension Spring 1
34 40421-053 Flange Tapping Screw 2
35 40410-026 Heat Shrinkable Tube 1
36 40439-021 Self Tapping Screw 4
37 40421-056 Motor Cover 1
38 40421-057 Motor Assembly 1
38-1 40421-058 Fan Blade 1
38-2 40421-059 Brushless Motor 1
39 40421-060 Closing Plug 2
To Next Page
