Item Stock # Description Item Stock # Description
1 70716-001 Screw 39 70716-039 Binding post
2 70716-002 Motor cover 40 70716-040 Screw
3 70716-003 Screw 42 70716-042 Trigger
4 70716-004 Brush spring 43 70716-043 Trigger switch
5 70716-005 Brush hold 45 70716-045 Adjust knob
6 70716-006 Carbon brush 46 70716-046 Nut
7 70716-007 Screw 47 70716-047 Screw
8 70716-008 Spring washer 48 70716-048 Nut
9 70716-009 Washer 49 70716-049 Saw arm
10 70716-010 Motor housing 50 70716-050 Bearing
11 70716-011 Rubber boot 51 70716-051 C clip
12 70716-012 Wave washer 52 70716-052 Gear
13 70716-013 Bearing 53 70716-053 Washer
14 70716-014 Armature 54 70716-054 Key
15 70716-015 Stator 55 70716-055 Spindle
16 70716-016 Fan baffle 56 70716-056 Bearing
17 70716-017 Screw 57 70716-057 Screw
18 70716-018 Bearing 58 70716-058 Washer
19 70716-019 Anti-finger touch plate 59 70716-059 Cover
20 70716-020 Lock washer 60 70716-060 Screw
21 70716-021 Screw 61 70716-061 Inner flange
22 70716-022 E clip 62 70716-062 Blade
23 70716-023 Lock pin spring 63 70716-063 Outer flange
24 70716-024 Lock pin 64 70716-064 Arbor bolt
25 70716-025 Screw 65-76 70716-065 Blade guard assembly
26 70716-026 Nut 77 70716-077 Screw
27 70716-027 Lower handle 78 70716-078 Guard retraction arm
28 70716-028 Cord clamp 79 70716-079 Shoulder Screw
29 70716-029 Power cord
80 70716-080 Screw
32 70716-032 Screw 81 70716-081 Wave washer
33 70716-033 Cord protector 82 70716-082 Bracket
34 70716-034 Upper handle 83 70716-083 Rubber pole
35 70716-035 Screw 84 70716-084 Spring washer
36 70716-036 Lower carry handle 85 70716-085 Screw
37 70716-037 Upper carry handle 86 70716-086 Big screw
38 70716-038 Screw 87 70716-087 Trench depth bracket
18
