Know your product
Before using the saw, familiarize yourself with all the operating features and safety requirements.
1
15
14
13
12
11
16
2
3
4
5
10
6
7
9
8
1. Operating Handle 11. Bevel Lock Knob
2. ON/OFF Switch 12. Slide Bar
3. Blade Guard 13. Slide Lock knob
4. Fence 14. Dust Extraction Port
5. Miter Table 15. Guard Retraction Arm
6. Table Insert 16. Carrying Handle
7. Miter Lock
8. Miter Scale
9. Support Arm
10. Clamp Assembly
