Wen 70716 User Manual

Specifications
Model Number 70716
Input Power 120V, 60Hz, 15A
No Load Speed 5500 RPM
Blade Size 10" x 5/8" bore
Number of teeth 60
MiterTable Angles 0° to 52° Left & Right
Bevel Cuts 0° to 45° Left only
Weight 29.7 lbs
Cutting Capacity
Straight cut at 0° miter, 0° bevel: 3-1/4x11-/5/8"
Miter cut at 45° miter, 0° bevel: 3-1/4x8-1/16"
Bevel cut at 0° miter, 45° left bevel: 1-5/8x11-5/8"
Compound miter cut at 45° left miter, 45° left bevel: 1-5/8x8-1/16"
The WEN 10" Sliding Compound Miter Sawis supplied with the following accessories as standard:
• Saw blade (installed)
• Hold down clamp
• 6 mm hex key
• 2 material support arms
• Dust collection bag
• Instruction manual
