EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 CM1452-001 Screw M5x12 2
2 CM1446-002 Dust Filter 1
3 CM1452-003 Bearing Support Plate 1
4 CM1452-005 Screw M5x10 2
5 CM1452-006 Red Gasket 2
6 CM1446-006 Label 1
7 CM1452-008 Bolt M5x15 2
8 CM1452-009 Depth Stop 1
9 CM1452-010 Motor Housing 1
10 CM1446-010 Chain Shaft 1
11 CM1446-011 Flat Washer 1
12 CM1446-012 Spring Washer 6 1
13 CM1446-013 Hexagon Nut M6 1
14 CM1446-014 Warning Sign 1
15 CM1452-012 Washer 5 mm 1
16 CM1452-013 Screw M5x10 1
17 CM1452-028 Switch Button Spring 1
18 CM1452-027 Safety Button 1
19 CM1452-026 Lower Handle 1
20 CM1452-018 Screw ST4.2x13 2
21 CM1452-031 Switch 1
22 CM1452-023 Switch Knob 1
23 CM1452-014 Left Handle 1
24 CM1452-015 Screw ST4.2x25 1
25 CM1452-016 Screw M5x60 2
26 CM1452-017 Screw M5x30 1
27 CM1452-029 Upper Handle 1
28 CM1452-025 Screw ST4.2x16 9
29 CM1452-021 Power Cord 1
30 CM1452-020 Cable Sheath 1
31 CM1452-022 Right Handle 1
32 CM1446-032 Screw ST4.2x15 2
33 CM1452-019 Cable Clamp 1
34 CM1452-024 Nut M5 3
35 CM1452-033 Protective Ring 1
36 CM1452-034 Brush Holder 2
37 CM1452-035 Carbon Brush 2
38 CM1452-036 Brush Cap 2
No. Part No. Description Qty.
39 CM1452-037 Stator 1
40 CM1452-038 Spring Washer 5 2
41 CM1452-039 Screw M5x80 2
42 CM1452-040 Air Baffle 1
43 CM1452-041 Bearing 6200 1
44 CM1452-042 Rotor 1
45 CM1452-043 Bearing 6202 1
46 CM1452-044 Inner Gearbox 1
47 CM1452-045 Locating Pin 2
48 CM1452-046 Stop Pin Spring 1
49 CM1452-047 Split Washer 8 1
50 CM1452-048 Arbor Lock 1
51 CM1452-049 Bearing 6000 1
52 CM1452-050 Gear 1
53 CM1452-051 Flat Key 5x12 1
54 CM1452-052 Small Output Shaft 1
55 CM1452-053 Bearing 6200 1
56 CM1452-054 Bearing 6001 1
57 CM1452-055 Gear Big 1
58 CM1452-056 Flat Key 6x12 2
59 CM1452-057 Large Output Shaft 1
60 CM1452-058 Bearing 6204 1
61 CM1452-059 Outer Gearbox 1
62 CM1452-060 Gearshaft Cover 1
63 CM1452-061 Screw M4x12 3
64 CM1446-064 Main Blade Guard 1
65 CM1446-065 Tension Spring 2
66 CM1452-066 Screw M5x90 4
67 CM1446-067 Lower Blade Guard 1
68 CM1446-068 Upper Blade Guard 1
69 CM1452-080 Circlip For Shaft 1
70 CM1452-081 Inner Flange 1
71 CM1452-077 Screw 4 4
72 CM1446-072 Connection Rod 2 1
73 CM1446-073 Connection Rod 1 1
74 CM1446-074 Lock Nut M5 4
75 BL1466 Blade 1
76 CM1452-092 Outer Flange 1
NOTE: Not all parts may be available for purchase.
