21
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
77 CM1452-093 Blade Washer 1
78 CM1452-094 Spring Washer 10 1
79 CM1452-095 Bolt M10x30 1
80 CM1446-080 Cover Plate 1
81 CM1446-081 Positioning Screw 1
82 CM1452-090 Blade Cover Screw 1
83 CM1446-083 Blade Guard Label 1
84 CM1452-096 Crank Handle Knob 1
85 CM1452-097 Vise Screw 1
86 CM1446-086 Vice Screw Support 1
87 CM1446-087 Flat Washer 8 2
88 CM1446-088 Spring Washer 8 2
89 CM1446-089 Bolt M8x30 2
90 CM1452-102 Flat Washer 8 2
91 CM1446-091 Connection Rod 3 1
92 CM1452-106 Cotter Pin 3x26 1
93 CM1446-093 Moving Vise Jaw 1
94 CM1452-108 Circlip For Shaft 22 1
95 CM1446-095 Back Fence 1
96 CM1452-112 Flat Washer 10 2
97 CM1452-113 Spring Washer 10 2
98 CM1452-114 Bolt M10x20 2
99 CM1446-099 Foot Support 3
100 CM1446-100 Rubber Foot 3
No. Part No. Description Qty.
101 CM1446-101 Flat Washer 6 3
102 CM1446-102 Screw M6x25 3
103 CM1446-103 Saw Base 1
104 CM1446-104 Bolt M6x20 1
105 CM1446-105 Flat Washer 6 1
106 CM1446-106 Plunge Chain 1
107 CM1446-107 Depth Stop Holder 1
108 CM1446-108 Nut M8 1
109 CM1446-109 Screw M8x40 1
110 CM1446-110 Torsional Spring Foot 1
111 CM1446-111 Nut M6 1
112 CM1446-112 Spring Washer 6 1
113 CM1446-113 Flat Washer 6 1
114 CM1446-114 Bolt M6x20 1
115 CM1446-115 Screw M5x15 2
116 CM1446-116 Circlip For Shaft 24 2
117 CM1446-117 Axle 1
118 CM1446-118 Torsion Spring 1
119 CM1446-119 Connection Plate 1
120 CM1446-120 Flat Washer 6 2
121 CM1446-121 Spring Washer 6 2
122 CM1446-122 Bolt M6x25 2
123 CM1446-123 Protection Board 1
124 CM1446-124 Screw M5x8 2
NOTE: Not all parts may be available for purchase.
