EXPLODED VIEW & PARTS LIST
No. Part. No. Description Qty.
1 MM1214-001 Base 1
2 MM1214-002 Foot 4
3 MM1214-003
M4 x 12 Self-Tapping
Screw
4
4 MM1214-004 Ø2 x 4 Rivet 2
5 MM1214-005 Miter Scale 1
6 MM1214-006 M8 x 55 Hex Bolt 1
7 MM1214-007 M5 x 6 Cross Head Screw 2
8 MM1214-008
M6 x 25 Table Extension
Knob
2
9 MM1214-009 Table Extension Rod 4
10 MM1214-010 M5 Lock Nut 3
11 MM1214-011
Table Extension Block
(Left)
1
12 MM1214-012 M5 x 8 Cross Head Screw 4
13 MM1214-013
Left Table Extension Stop
Plate
1
14 MM1214-014
M5 x 20 Cross Head
Screw
9
15 MM1214-015
M6 x 10 Cross Head
Screw
4
16 MM1214-016 Anti-Tip Support 1
17 MM1214-017 Swivel Plate 2
18 MM1214-018 Fence 1
19 MM1214-019 M6 x 32 Knob 2
20 MM1214-020 M8 Flat Washer 4
21 MM1214-021 M8 x 25 Hex Screw 2
22 MM1214-022 M8 Spring Washer 4
23 MM1214-023 M8 x 35 Hex Screw 2
24 MM1214-024 Left Fence Extension 1
25 MM1214-025 Right Fence Extension 1
26 MM1214-026 M12 Washer 1
27 MM1214-027
M5 x 10 Cross Head
Screw
1
28 MM1214-028 Lock Nut 1
29 MM1214-029 Locking Rod 1
30 MM1214-030 Bevel Lock Lever 1
31 MM1214-031 M5 Flat Washer 9
32 MM1214-032 M5 x 10 Hex Screw 1
33 MM1214-033 Miter Detent Lever 1
34 MM1214-034 Compression Spring 1
No. Part. No. Description Qty.
35 MM1214-035
Table Extension Block
(Right)
1
36 MM1214-036
Right Table Extension
Stop Plate
1
37 MM1214-037 Miter Lock Knob 1
38 MM1214-038 Miter Lock Knob Washer 1
39 MM1214-039
M5 x 35 Socket Head
Screw
1
40 MM1214-040 Small Press Board 1
41 MM1214-041 M4 x 8 Cross Head Screw 8
42 MM1214-042 Kerf Board 1
43 MM1214-043 Table 1
44 MM1214-044 Miter Angle Indicator 1
45 MM1214-045
M5 x 10 Cross Head
Screw
17
46 MM1214-046 M8 Flat Washer 1
47 MM1214-047 M8 Lock Nut 2
48 MM1214-048 Bevel Scale 1
49 MM1214-049 M8 x 20 Hex Screw 2
50 MM1214-050 Bevel Hinge 1
51 MM1214-051 Lock-Down Pin 1
52 MM1214-052 Lock-Down Spring 1
53 MM1214-053 Lock-Down Pin Head 1
54 MM1214-054
Ø3 x 16 Spring Cylindrical
Pin
1
55 MM1214-055 Depth Stop 1
56 MM1214-056 M8 Wavy Washer 2
57 MM1214-057 M8 Pan Head Bolt 1
58 MM1214-058 Bearing Cover 2
59 MM1214-059
M4 x 10 Cross Head
Screw
1
60 MM1214-060 Bevel Angle Indicator 1
61 MM1214-061 Table Support 1
62 MM1214-062 Stop Pin 2
63 MM1214-063 M10 Hex Nut 1
64 MM1214-064 M6 Flat Washer 8
65 MM1214-065 Bevel Stop Block 1
66 MM1214-066
M6 x 16 Non-Standard
Screw
1
67 MM1214-067
M6 x 14 Cross Head
Screw
3
