Wen MM1214 User Manual

2524
EXPLODED VIEW & PARTS LIST
No. Part. No. Description Qty.
68 MM1214-068 M6 Spring Washer 8
69 MM1214-069 M6 x 10 Cross Bolt 1
70 MM1214-070 Connecting Bar Support 1
71 MM1214-071 M6 Lock Nut 2
72 MM1214-072 Hinge Pin 1
73 MM1214-073 Spring Sleeve 2
74 MM1214-074 Torsion Spring 1
75 MM1214-075 M10 x 80 Stud 1
76 MM1214-076 Locking Rod 1
77 MM1214-077 M8 x 25 Zero Stop Screw 1
78 MM1214-078 M8 Zero Stop Lock Nut 1
79 MM1214-079 M6 x 25 Slide Lock Knob 1
80 MM1214-080 Spring 1
81 MM1214-081 M10 x M28 x 3 Flat Washer 1
82 MM1214-082 M10 Lock Nut 1
83 MM1214-083
Ø45 x Ø30 x 35 Linear
Bearing
4
84 MM1214-084 Slide Rail 2
85 MM1214-085 Ø5 x 44 Roll Pin 2
86 MM1214-086 Slide Rail Cover 1
87 MM1214-087 Cable Clamp 2
88 MM1214-088
M8 x 18 Arbor Screw
(Left)
1
89 MM1214-089 Outer Flange 1
90 MM1214-090 Arbor Insert 1
91 MM1214B TCT 12 in. Blade 1
92 MM1214-092 Inner Flange 1
93 MM1214-093
M5 x 40 Cross Pan Head
Screw
2
94 MM1214-094 M5 Spring Washer 9
95 MM1214-095 Gearbox Cover 1
96 MM1214-096 Gasket 1
97 MM1214-097 6003 Bearing 1
98 MM1214-098 Bearing Retainer 1
99 MM1214-099 M4 Spring Washer 2
100 MM1214-100
M4 x 12 Cross Head
Screw
2
101 MM1214-101 Spindle 1
102 MM1214-102 Flat Key 4 x 4 x 8 1
103 MM1214-103 Large Gear 1
104 MM1214-104 Ø15 Retaining Ring 1
No. Part. No. Description Qty.
105 MM1214-105 Roller Bearing HK1010 1
106 MM1214-106 Guard Label 1
107 MM1214-107 M6 x 10 Set Screw 2
108 MM1214-108 Upper Blade Guard 1
109 MM1214-109
Upper Blade Guard
Bushing
1
110 MM1214-110 6001 Bearing 1
111 MM1214-111 Flat Key 4 x 4 x 20 1
112 MM1214-112 Gear Shaft 1
113 MM1214-113 Brush Holder Cap 2
114 MM1214-114 Carbon Brush 2
115 MM1214-115 Brush Holder 2
116 MM1214-116
M5 x 35 Cross Head
Screw
4
117 MM1214-117 Motor Housing 1
118 MM1214-118 Motor Housing Label 1
119 MM1214-119 Stator 1
120 MM1214-120
ST4.8 x 65 Self-Tapping
Screw
2
121 MM1214-121 Seal 1
122 MM1214-122 6000 Bearing 1
123 MM1214-123 Rotor 1
124 MM1214-124 6002 Bearing 1
125 MM1214-125 Middle Cover 1
126 MM1214-126 M8 x 25 Set Screw 1
127 MM1214-127 Small Pulley 1
130 MM1214-130
Lower Blade Guard
Washer
1
131 MM1214-131 Connecting Bar Screw 1
132 MM1214-132 Connecting Bar 1
133 MM1214-133 Lower Blade Guard Panel 1
134 MM1214-134
Lower Blade Guard Coil
Spring
1
135 MM1214-135
Lower Blade Guard
Washer
1
136 MM1214-136 Rubber Stopper 1
137 MM1214-137 M6 x 7 Flat Head Bolt 1
138 MM1214-138 Guard Plate 1
139 MM1214-139 Lower Blade Guard 1
140 MM1214-140 M6 x 14 Hex Screw 1
141 MM1214-141 Dust Collection Bag 1
