KNOW YOUR MITER SAW
10
TOOL PURPOSE
Miter saws allow you to easily make cuts at a variety of angles. Refer to the following diagrams to become familiar-
ized with all the parts and controls of your miter saw. The components will be referred to later in the manual for
assembly and operation instructions.
1
2
3
5
6
7
8
9
10
1117
15
14
4
13
12
1. Operating Handle
2. Upper Blade Guard
3. Lower Blade Guard
4. Bevel Scale
5. Right Adjustable Fence
12. Sliding Bar
13. Sliding Bar Lock Knob
14. Workpiece Clamp
15. Left Adjustable Fence
16. Side Carrying Handles
17. Miter Table
6. Base
7. Mounting Hole
8. Table Insert
9. Miter Angle Adjustment Lever
10. Miter Lock Knob
11. Miter Scale
16
