Wen MM1215 User Manual

26
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
0-01 MM1215-001 Motor Assembly 1
0-02 MM1215-002 Pivot Assembly 1
0-03 MM1215-003 Base Assembly 1
0-04 MM1215-004
Quick-clamp
Assembly
1
0-05 MM1215-005 Blade Guard 1
0-06 MM1215-006
Miter Lock Handle
Assembly
1
0-07 MM1215-007 Bevel Lock Handle 1
0-08 MM1215-008 Arbor Assembly 1
0-09 MM1215-009
Cross-head Screws
M4X12
3
0-10 MM1215-010 Cord Clip 3
0-11 MM1215-011 Set Screws M6X22 1
0-12 MM1215-012 Spring 1
0-13 MM1215-013 Dust Bag 1
0-14 MM1215-014 Set Screws M6X22 1
0-15 MM1215-015 Bevel Scale 1
0-16 MM1215-016
Cross-head Screws
M5X16
2
0-17 MM1215-017 Inner Flange 1
0-18 MM1215-018 Saw Blade 1
0-19 MM1215-019 Outer Flange 1
No. Part No. Description Qty.
0-20 MM1215-020
Socket Screws
M8X16
1
0-21 MM1215-021 Lock Nut M6 1
0-22 MM1215-022 Wave Washer 1
0-23 MM1215-023 Linkage 1
0-24 MM1215-024
Shoulder Screws
M5X10
1
0-25 MM1215-025 Screws M6X16 1
0-26 MM1215-026
Socket Screws
M5X16
1
0-27 MM1215-027
Shoulder Screws
M6X14
1
0-28 MM1215-028 Lock Pin 1
0-29 MM1215-029 C-ring 1
0-30 MM1215-030 Lock Nut M12 1
0-31 MM1215-031 Washer 2
0-32 MM1215-032 Wave Washer 1
0-33 MM1215-033 Set Screws M8X35 1
0-34 MM1215-034 Washer 1
0-35 MM1215-035 Set Screws M8X25 1
0-36 MM1215-036 Pivot Shaft 1
0-37 MM1215-037 Spring Sleeve 1
0-38 MM1215-038 Dust port 1
MITER SAW
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.
