Wen MM1215 User Manual

28
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1-01 MM1215-101
Cross-head Screws
M5X35
6
1-02 MM1215-102
Self-tapping
Screws
3
1-03 MM1215-103 Upper Handle 1
1-04 MM1215-104 Spring 1
1-05 MM1215-105 Switch 1
1-06 MM1215-106
Switch Trigger
Assembly
1
1-07 MM1215-107
Self-tapping
screws
6
1-08 MM1215-108 Cord Bracket 1
1-09 MM1215-109 LED Switch Cover 1
1-10 MM1215-110 LED Switch 1
1-11 MM1215-111 Transformer 1
1-12 MM1215-112 Capacitor 1
1-13 MM1215-113 Lower Handle 1
1-14 MM1215-114 Cable Sheath 1
1-15 MM1215-115 Power Cord 1
1-16 MM1215-116
Cross-head Screws
M6X20
2
1-17 MM1215-117 Washer 2
1-18 MM1215-118 Carry Handle 1
1-19 MM1215-119
Cross-head screws
M5X20
4
1-20 MM1215-120
Lower Handle
Bracket
1
1-21 MM1215-121 Logo 1
1-22 MM1215-122 Upper Blade Guard 1
1-23 MM1215-123 Brush End Cap 2
1-24 MM1215-124 Carbon Brush 2
1-25 MM1215-125
Carbon Brush
Holder
2
1-26 MM1215-126 Rating Label 1
No. Part No. Description Qty.
1-27 MM1215-127 Motor Housing 1
1-28 MM1215-128 Warning Label 1
1-29 MM1215-129
Cross-head Screws
M5X30
2
1-30 MM1215-130 Set Screws M6X10 2
1-31 MM1215-131 Motor End Cap 1
1-32 MM1215-132 Stator 1
1-33 MM1215-133
Self-tapping
Screws
2
1-34 MM1215-134 Bearing Sleeve 1
1-35 MM1215-135 Bearing 2
1-36 MM1215-136 Armature 1
1-37 MM1215-137 C-ring 1
1-38 MM1215-138 Bearing 2
1-39 MM1215-139 Baffle 1
1-40 MM1215-140 Knob 1
1-41 MM1215-141 Nut 1
1-42 MM1215-142 Lock Pin 1
1-43 MM1215-143 Spring 1
1-44 MM1215-144 E-ring 1
1-45 MM1215-145 Screws 3
1-46 MM1215-146 Bearing 1
1-47 MM1215-147 Hex Nut 1
1-48 MM1215-148 Socket Screws 1
1-49 MM1215-149 Rubber Deflector 1
1-50 MM1215-150 LED 1
1-51 MM1215-151 LED Lamp 1
1-52 MM1215-152 LED Cover 1
1-53 MM1215-153 LED Left Cover 1
1-54 MM1215-154 LED Right Cover 1
1-55 MM1215-155
Self-tapping
Screws
2
1-56 MM1215-156 Chip Deflector 1
MOTOR ASSEMBLY
