Westermann WKB 330 - Commissioning Procedures; Adjusting the Handle Height; Engine Start WKB 330

26
ENGLISH
9 Commissioning
9 Commissioning
For commissioning, the walk-behind sweeper is moved from the rest po-
sition to the working position.
9.1 Adjusting the handle height
A handle height adjustment is provided for the adjustment of the handle
height, which can be adjusted without tools. This makes it easy to adjust
the handle height for different body heights in the shortest possible time
in an ergonomically favourable way.
9.1.1 Adjustment process
  P  P Loosen the wing nut on the inside.
PP Pull up the bar and move it to the desired
position
PP Lower the bar so that the screw falls into
the cut-out.
PP Tighten the wing nut.
9.2 Engine start WKB 330
See enclosed motor operating instructions
(Fig. 4 - Handle height)
