CP600 Pivot Operation Manual
POM-EN-December 2018
101
6. Future Option: N/A
7. Future Option: N/A
8. Option Auto Restart O / On: Overrides the Auto-Restart option, and prevents the machine from
starting in the event of a power outage, or from automatically starting the machine from a remote
location.
9. Dry, Wet, Aux: Dry-No water or fertilizer; Wet-water only; Aux- Water and Fertilizer.
10. Determines the direction of travel and enables the auto-reverse or auto-o feature. If the au-
to-reverse feature is used, turn the selector switch to AUTO and turn the Stop-Run-Start switch
to Start. The machine will travel in the direction that the Auto Reverse option is currently set to. If
Auto O is used, simply place the selector switch in the desired direction, then Start the system.
Machine will move in the selected direction and stop when the machine reaches the barricade.
Note: Forward is to be clockwise.
11. Stop, Run, Start: Stop or Start machine
WARNING! CARE SHOULD BE TAKEN WHEN USING THE SAFETY OVERRIDE FEA-
TURE. SEVERE MISALIGNMENT MAY RESULT IN STRUCTURAL DAMAGE. DO NOT
USE OVERRIDE UNLESS MACHINE IS IN COMPLETE VIEW.
12. Safety Override: The machine shutdown feature may be overridden by pressing the safety
override button and turning the Stop, Run, Start switch to “START”.
13. iControlRemote
See Section 1-6 for proper machine alignment.
Section 4-3
Panel Operation
Panel Identification
To Next Page
