Western CP600 - Towable Pivot Pad (Concrete)

CP600 Pivot Operation Manual
POM-EN-December 2018
96
Figure 3-13.
3988
157”
3988
157”
6” REINFORCING MESH
457
18”
152
6”
305
12”
813
32”
2362
93”
813
32”
914
36”
3683
145”
3683
145”
#4 REBAR PERIMETER
USE CHAIN WITH A PROOF LOAD OF AT LEAST
24.000 LBS {1/2” GRADE 8}. CONSULT CHAIN
MANUFACTURER. THREAD REBAR THROUGH
END LINK
DETAIL A
SCALE 1 : 25
PAD REQUIRES APPROXIMATELY
6.7 CUBIC YARDS OF CONCRETE
Section 3-14
Getting Started
Towable Pivot Pad (Concrete)
