GOOD BAD BAD BAD
Rotation Forward = Clockwise
Desired
Bow
Too Much
Leading Bow
Trailing
Bow
Crooked
Total Bow For
System is About
One Tire Width
Figure 1-8.
Section 1-8
Operation, Safety & Maintenance
Machine Alignment
