CP600 Pivot Operation Manual
POM-EN-December 2018
22
B. Worm gear center drive gearbox lubricants:
A GL-5 SAE 140 or MIL C-2105 gear lube must be in worm gear center drive gearboxes. Some
common brands meeting this specication are listed in section B of Final Drive Gearbox. Oil ca-
pacity is 3 ½ U.S. pints (1.6 Liters) approximately.
C. In-season worm gear center drive maintenance:
1. Proper oil level (mid bull gear) should be maintained at all times.
2. Contaminated or emulsied oil should be replaced with fresh oil.
3. Input and output shaft seals should be inspected for excessive leaks and should be re
placed if necessary.
A. Driveline Coupler Maintenance
1. Drive line couplers should be inspected periodically for loose bolts and worn rubber inserts.
Worn inserts should be replaced.
Figure 1-18.
Section 1-18
Operation, Safety & Maintenance
Power Drivetrain Maintenance
