WHEATON
®
OmniSpense
®
ELITE Peristaltic Pump
WHEATON | 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | www.wheaton.com | P/N 50099067 Rev. 5/15/12 WMAN_001
13
9.1 Pump Head Selection
Use the UP and DOWN to move to the pump head icon and select pump head. Use the LEFT and RIGHT
arrow keys to select pump head:
Single Pump
Head 312 / 314
Multiple Pump
Heads 312 / 314
Cassette Pump
Model 304 / 308
9.2 Pump Direction
Use the UP and DOWN keys to move to the pump direction icon. Use the LEFT and RIGHT arrow keys to
select either clockwise or counterclockwise direction:
Clockwise
Counterclockwise
9.3 Tubing Size
Use the UP and DOWN keys to move to the tubing icon. Use the LEFT and RIGHT arrows to navigate the
number fields, and the UP and DOWN icons to adjust the number fields. Press the OK button when done.
10.0 Making a Calibration
Use the UP and DOWN arrows in the HOME screen to navigate to the calibration icon.
