WHEATON
®
OmniSpense
®
ELITE Peristaltic Pump
WHEATON | 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | www.wheaton.com | P/N 50099067 Rev. 5/15/12 WMAN_001
14
Press OK to navigate to the CALIBRATE screen.
10.1 Setting Calibration Speed
Use the LEFT and RIGHT buttons to select the calibration speed:
Slow calibration speed
Fast calibration speed
10.2 Priming the Tubing
Use the UP and DOWN buttons to select the PRIME icon. The PRIME button on the keypad now
becomes active. Push and HOLD the prime button on the keypad to run the pump motor and purge any
air from the tubing. RELEASE the prime button to stop the motor.
10.3 Calibration Dispense
Use the UP and DOWN button to navigate the Calibration Dispense icon:
Prepare to measure a dispense by using a graduated cylinder, electronic scale, or other device that can
accurately measure volume. Press the START / STOP button to begin a calibration dispense. For
best results, the pump rotor should make at least ten (10) revolutions.
Calibrate Screen
Pump Running /
Stopped Icon
Active Keys
