Wheaton W375030-A - 11.6 Soft Start; Ramping; 11.7 Making a Dispense

WHEATON
®
OmniSpense
®
ELITE Peristaltic Pump
WHEATON | 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | www.wheaton.com | P/N 50099067 Rev. 5/15/12 WMAN_001
17
Example 1: Dispense Volume set to 100 mL, Drawback Volume set to 5 mL
Use the UP and DOWN and the LEFT and RIGHT keys to enter the drawback volume. Press OK when
done.
11.6 Soft Start / Ramping
Use the UP and DOWN keys to navigate to the Ramp icon:
Press the RIGHT key then use the UP and DOWN keys to set the starting ramp:
No ramping
Maximum ramping
Press OK when done.
11.7 Making a Dispense
Press the START / STOP button to start a batch dispense:
