FIGURE B – Lower Housing Assembly
ITEM
USE QTY.
WHEATON NO.
DESCRIPTION
1
1
50099004
ALUMINUM BASE CABINET
2
1
WI056857
PCBA, REMOTE I/O
3
1
WI056858
MOTOR, STEPPER
4
1
WI056859
UNIVERSAL POWER SUPPLY, 48V, 3.2A
5
1
50099058
POWER SUPPLY STABILIZER BRACKET
6
1
WI056856
PCBA, CPU, OMNISPENSE ELITE
7
1
WI056863
POWER INLET
8
1
WI056860
POWER SWITCH
9
4
50099059
ADHESIVE RUBBER FEET
10
1
50099060
PUMP HEAD DRIVE ADAPTER
11
2
I052353
SCW, SET, #10-32 X 1/4" LG
12
4
50099061
SCW, SET, 10-32 X 1/2" LG
13
4
50099062
SCW, M4X8, SS, PPHM
14
1
I052239
SCW, 6-32 X 1/4 PPHM
15
1
50029919
NUT,HEX,6-32
16
1
I052273
WASHER,STAR,#6,INT TOOTH
17
1
50099063
STF, 6-32 X 1/4, ALUMINUM
18
2
WI056864
FUSE, 5X20MM, 2.0AT, 250V (120V)
18
2
WI056862
FUSE, 5X20MM, 1.0AT, 250V
FIGURES C THRU E – Upper Housing Assembly, Main Assembly and Wiring Diagram
ITEM
USE QTY.
WHEATON NO.
DESCRIPTION
19
1
50099005
PLASTIC UPPER HOUSING, CABINET
20
1
WI056861
LCD, DISPLAY, 240 X 128, BACKLIT
21
1
50099069
CONTROL KEYPAD OVERLAY, OMNISPENSE
ELITE
22
4
50099068
SCW, PLASTITE 48, TRILOBE, #4 X 0.250
23
1
50099006
SCREEN, VENT, PLASTIC
24
4
50099758
#8 X 1-1/4” PHIL PAN HEAD SCREW
25
1
50099065
ASS'Y, WIRE HNS, OMNI ELITE
26
1
50028826
LABEL, LINE VOLTAGE
27
1
50027794
LABEL, UL APPROVED, SERIAL #
28
1
50028394
LABEL, MET NRTL LISTED, OMNI / FLOW
29
1
50028414
LABEL, CAUTION
30
1
50028416
LABEL,CE (MARK) (230V)
