DUCTING CONFIGURATIONS
Fully Ducted
Heat Exhaust
Cold Air Supply — Cellar Side
Condenser Intake
Return Air — Cellar Side
Condenser Exhaust
Cold Air
Return Air
Condenser
Intake
Fresh Air Intake
Attic Mounted Unit
It is recommended that you use a condensate pan for this application.
NOTE: The condenser intake air must
remain between 42°F and 110°F.
