PH 080718
Page 12 | 1-800-343-9463
REORIENTING THE CONTROLLER BOX
1. First, unclip the wires from the twist clip.
2. Then, using an ⁄" nut driver, remove the two (2) 8-32 Keps nuts
securing the transformer to the divider.
3. Move the transformer to the left and resecure using the two (2)
8-32 Keps nuts removed earlier.
4. Resecure the wires using the twist clip.
Twist clip
NOTE: These instructions only apply when reorienting the evaporator
blower to the right.
To Next Page
