PH 080718
Page 6 | 1-800-343-9463
UNIT SPECIFICATIONS
3500 5000 8000
Dimensions
15.75”H x 15.75”W x 37”L (without duct plenums)
22.75” H x 15.75” W x 48”L (duct plenums on top of unit)
15.75” H x 22.75” W x 48”L (duct plenums on side of unit)
BTUh (with 85°F air
entering condenser
coil)
4060 5521 6025
CFM
326 (top); 312 (side) 326 (top); 312 (side) 340 (top); 335 (side)
Cellar Size*
800 cu. ft. 1250 cu. ft. 2000 cu.ft
Duct Sizing
8” supply
10” return
8” supply
10” return
8” supply
10” return
Weight (lbs.)
113 116 125
Amps (running)
8.0 8.8 12.6
dBA
In cellar: 40 • Adjacent to unit: 50
Installation
Fully ducted (attic or maintenance room)
Thermostat
Aftermarket (24V thermostat not included)
Temp. Delta
55°F temperature dierential
(maintains proper cellar temperature when exhaust environment remains between 42°F and 110°F)
Outside Venting
Can be done if the outside temperature remains between 42°F and 110°F
Warranty
Two-year limited warranty (parts and labor)
* Sizing the Unit to the Room
The specication chart will provide information on the unit's cooling capacity. There are circumstances in which a cellar design may
require a larger unit due to preexisting design restrictions. Certain building materials such as glass, stone, or concrete may seem
adequate but do not oer the insulation capacity required to maintain the optimum temperature for storing wine. We recommend
purchasing a unit with a larger capacity to compensate for these design limitations. Undersized cooling units can lead to premature
failure and/or prevent the system from reaching the desired set temperature. As a result, undersized cooling units are not covered
under warranty.
