Whitfield ADVANTAGE PLUS - Shroud Panel Access; Shroud Panel Dimensions

APPENDIX C
SHROUD PANEL ACCESS
28.50”
(Sml)
32.00”
(Med)
36.00”
(Lrg)
40.75”(Sml)
44.00”(Med)
48.00”(Lrg)
22”
Shrouds and
magnetic shroud
trim are available in
three sizes for your
Advantage Insert:
Small:
28.5”(72.4 cm) high by
40.3/4”(103.5 cm) wide
Medium:
32”(81.3 cm) high by
44”(111.75 cm) wide
Large:
36”(91.4 cm) high by
48”(121.9 cm) wide
