Installation and operating instructions WILO Mather and Platt – VT pumps 7
Fig. 7: Leveling of sole plate (Page No. 25, Point No. 7.2)
Fig. 8: Support to the discharge piping (Page No. 31, Point No. 8.10)
Fig. 9: Alignment of pump-motor coupling (Page No. 29, Point No. 8.7)
