Wilo Wilo-Drain TS 50 Series User Manual

English
34 WILO SE 07/2014 V4.1
• S3 3 min
Operation 3 min/standstill 7 min
If two values are given, they relate to each other e.g.:
• S3 5 min/20 min
Operation 5 min/standstill 15 min
• S3 25%/20 min
Operation 5 min/standstill 15 min
4.6 Technical data
* Explosion protection only with products with three-
phase current motor and without float switch!
1)
Maximum operating period: 200 h/a
4.7 Type code
4.8 Scope of delivery
• Unit with 10 m cable
• AC version with
• capacitor box, float switch, and Schuko plug
• Three-phase current version, type-dependent, with
• float switch and CEE plug
• CEE plug
• free cable end
• Installation and operation manual
4.9 Accessories (optionally available)
• Products with cable lengths up to 30 m (1~230 V/
50 Hz) or 50 m (3~400 V/50 Hz) in fixed increments of
10 m
• Suspension unit (for TP units only)
• Various discharge ports and chains
• Storz couplings
• Fixing accessories
• Switching devices, relays and plugs
• Hoses
5 Installation
In order to prevent damage to the product or serious
injury during installation, the following points must be
observed:
• Installation work – assembly and installation of the
machine – may only be carried out by qualified per-
sons. The safety instructions must be followed at all
times.
• The machine must be inspected for transport damage
before carrying out any installation work.
5.1 General
For planning and operation of technical waste water
systems, attention is drawn to the pertinent local regu-
lations and directives for waste water technology (such
General data
Mains supply: see type plate
Power consumption P
1
: see type plate
Rated motor capacity P
2
: see type plate
Max. pump head: see type plate
Max. pump flow: see type plate
Activation type: direct
Liquid temperature: 3…35°C
Protection class: IP 68
Isolation class:
TS 50…/TS 65…: F
TP 50…/TP 65…: F
Speed: 2900 rpm
Max. submersion:
TS 50…/TS 65…: 10 m
TP 50…/TP 65…: 10 m
Operating modes
1)
Submerged: S1 / S3 25%
Emerged: S2-8 min
Starts per hour
Recommended: 20/h
Maximum:
TS…: 50/h
TP 50…: 70/h
TP 65…: 40/h
Explosion protection*
TS 50…/TS 65…/TP 65…: Ex d IIB T4
TP 50…: -
TS…-A/TP…-A: -
Discharge port
TS 50…: Rp 2
TS 65…: Rp 2½
TP 50…: DN 50, PN 10/16
TP 65…: DN 65, PN 10/16
Free flow diameter
TS…: 10 mm
TP…: 44 mm
Example: Wilo-Drain TS 50 H X 111/11-Ax
TS
Series:
TS = submersible motor pump for waste water
TP = submersible motor pump for waste water
and sewage
50 Nominal discharge port
H
Impeller shape:
E = single-channel impeller
F = free-flow impeller
H = semi-open channel impeller
X 1.4404 version
111 Impeller diameter in mm
11 /10 = rated motor capacity P
2
in kW
A
Version:
A = with float switch and plug
CEE = with CEE plug
Without = with free cable end
x
Mains supply
1-230 = AC connection
3-400 = three-phase current connection
