SCRUB CONTROLS-BASIC AND CYLINDRICAL
86037660 CHARIOT 11/09/06
3-9
1. Squeegee Lift Lever 3. Brush Pressure Indicator
2. Scrub Deck Actuator Switch 4. Solution Control Knob
4
3
2
1
