Windsor chariot iSCRUB CS24 10060210 - Squeegee

MAINTENANCE-SQUEEGEE
86037660 CHARIOT 11/09/06
4-6
1. Squeegee
2. Squeegee Deflection Adjustment Knobs
3. Squeegee Level Indicator
4. Squeegee Pitch Adjustment
Rod/Cylindrical Knob
5. Squeegee Pitch Adjustment Lock Nut
6. Squeegee Retainer Knob
DISK SCRUBBER
CYLINDRICAL SCRUBBER
5
6
4
6
4
3
2
1
