MAINTENANCE-BATTERIES
86037660 CHARIOT 11/09/06
4-2
1. Rear Cover Retainer Knob
2. Rear Cover
3. Battery Connector-Machine
4. Batteries
5. Battery Tray
6. Battery Tray Latch
1
2
3
4
5
6
