MAINTENANCE-SCRUB DECK – DISK
86037660 CHARIOT 11/09/06
4-10
1. Scrub deck Aqua-Mizer™
2. Aqua-Mizer™ retainer knob
3. Scrub deck skirt
4. Scrub deck skirt stop
5. Scrub brush motor
6. Scrub deck lift actuator
6
5
4
3
2
1
