Operations
Technical Specifications
ITEM DIMENSION/CAPACITY
Nominal Power 1600 W
Rated Voltage 36 Volts DC
Rated Amperage 43 Amps
Batteries 3 X 12 Volt 205-234 @ 20 hr. rate
Battery Compartment Dimensions 21in. X 16in. X 17in. (533mm X 406mm X 432mm)
Battery, Lithium 38.4 Volts
Battery, Lithium - Dimensions (375mm x 347.5 x 471.5 mm)
Propel Motor 0.75HP (560W)
Brush Motor 0.5 HP (373W)
Side Broom Motor 0.06HP (45W)
Bag Capacity 1006 in³ (16.5L)
Hopper Capacity 43.6 in³ (0.71L)
Brushes Two 28in (71cm) by 4in (10cm) dia.
Side Broom 13 inch (33cm)
Max Brush Speed 970 RPM
Max Side Broom speed 90 RPM
Vacuum Motor 0.94 HP (700W)
Max Flow Rate of vac motor 120 cfm (56.6 L/sec)
Vac bag full shut-off 14-16 inH2O (3.5 - 4.0 kPa)
Max suction vac motor 58.2 inH2O (14.5 kPa)
Weight (GVW) Gross weight with batteries and operator 958 Lb. (435 Kg)
Weight Empty no batteries or operator 361 Lb. (164Kg)
Tires 10in. (254mm) Solid grey non-marking
Foundation Pressure 61psi (420kPa)
Max Speed 3.65 MPH 5.88 Km/h
Frame construction Powder coated Steel
Brake
Electrical Brake (engaged when operator steps of or E-
Stop activated)
Minimum Aisle U-Turn 66.92 in. (1700 mm)
Max rated climb and Descent 10% (6 degrees)
Sound Pressure at operators ear (IEC 60704-1) 71.1 dBA Uncertainty 2.8dBA Hard Floor Norm Clean
Sound Power (IEC 60704-1) 84.9 dBA Uncertainty 2.8dBA Hard Floor Norm Clean
Sound Pressure at operators ear (IEC 60704-1) 65.8 dBA Uncertainty 2.5 dBA Carpet Daytime Clean
Sound Power (IEC 60704-1) 84.7 dBA Uncertainty 2.5 dBA Carpet Daytime Clean
Vibration Hands (ISO 5349) 0.77 m/sec² Uncertainty .5 m/sec²
Vibration Feet (ISO 5349) 0.08 m/sec² Uncertainty .5 m/sec²
8.641-374.0 operator’s manual - chariot 3 - cv86/1 rs bp
